The Non-Contact Diaphragm Jet™ — Only from Advanjet!

Easy to Clean. Outstanding Performance. Low Running Cost.

What makes Diaphragm-Jet technology different from other non-contact jets is the incredible simplicity of its patented design.

At its core is a unique, easily-replaceable diaphragm which totally eliminates dynamic fluid seals common in all other jets!

This unique diaphragm allows extremely fast cycle rates because of its tiny mass. (There’s no large sliding valve-stem slowing down the process!)

Unlike other jets, only two parts require cleaning which saves time and money.

The Diaphragm-Jet technology has the ability to adjust the energy needed to eject a drop, which means you can optimize your recipes for outstanding performance!

Take a look at our most popular jets that use Diaphragm-Jet™ Technology:

HV-2000 Jet HM-2500 Hot Melt Jet HV-9500 Standalone Jet

Incredibly Easy to Clean

Incredibly easy to clean

With only 2 parts contact the fluid and a disposable feedtube, cleaning the HV-2000 takes only minutes. Conventional jets can have as many as 8 parts requiring cleaning. There is no need to remove the jet from the robot. A diaphragm and nozzle plate install immediately without the need to carefully calibrate the jet saving valuable production time. And, no intricate, expensive cartridge to disassemble!

Outstanding Performance

Outstanding Performance
  • Speed – Continuous jetting at 300Hz will meet the demands of high-volume production!
  • Repeatability – Tested in the most challenging environments, the diaphragm jet has proven to generate consistently repeatable, high-quality drops and lines.
  • Capability – Achieve a high process capability and wide process window by adjusting the jet velocity to reduce accumulation of “stringy” fluids!
  • Reliability – The Diaphragm Jet is designed to last and last. And when it’s time for maintenance, parts can be quickly replaced at your factory.

Low Running Cost

Maintenance Kit

The simplicity of the Diaphragm Jet, with only two internally moving parts, delivers one of the industry’s lowest running cost per million cycles of the jet. Unlike piezo jets with costly replacement parts that require the jet to be sent out for repair, the Advanjet Diaphragm Jet can be completely maintained and repaired in your factory. The two moving pneumatic parts, the solenoid and cylinder have been extensively tested and provide reliable performance for up to 500M cycles with a fraction of the cost of a piezo jet actuator.
